Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes

TOBO STEEL GROUP CHINA
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes

  • 1
  • 2

Brand Name : TOBO/TPCO/TISCO/VALIN/METAL

Model Number : 1.4835 Stainless Steel Seamless Pipe

Certification : ISO/PED/TUV/SGS/LR/BV

Place of Origin : China/Japan/Germany

MOQ : 0.5-1 tons

Price : negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 7500 tons per year

Delivery Time : 15days->

Packaging Details : in plastic bags then in bundles

Standard : DIN, ANSI, ISO, GB, JIS

Sample : Provided,Free,Available free within 7days

Application : Fluid pipe,Structure Pipe

Outer Diameter : 6-813mm

Surface : Annealed & Pickled, Bright Annealing, Polished

Thickness : 0.5-100mm

Material : Carbon Steel,Stainless Steel,alloy steel,Brass,copper

Types : Seamless

Contact Now

Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes

Overview
Quick Details
Place of Origin:
China
Type:
Nickel Pipe
Application:
Industry
Grade:
Nickel Base Alloy, Inconel 600
Ni (Min):
72%
Resistance (μΩ.m):
Stable
Powder Or Not:
Not Powder
Ultimate Strength (≥ MPa):
585
Elongation (≥ %):
30 %
Model Number:
inconel 600
Brand Name:
Phoenix
Product name:
inconel 600 seamless pipes
Chemical Composition:
Ni,Cr,Fe,C,Mn,Si,Cu,P,S
Shape:
forging
Surface:
bright
Material:
Nickle Material
Color:
Nickel Nature
Condition:
Soft Annealed
Specification:
NO6600/W.Nr 2.4816
Standard:
ASTM B516
Supply Ability
Supply Ability
500 Ton/Tons per Month inconel 600
Packaging & Delivery
Packaging Details
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes
Standard seaworthy package (wooden boxes package, pvc package, and other package).or as buyers requirement
Port
shanghai port
Product Description
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes
Inconel 600 is resistant to corrosion by many organic and inorganic compounds and also makes it virtually immune to chloride-ion stress-corrosion cracking. Alloy 600 is used extensively in the chemical industry for its strength and corrosion resistance. Applications include heaters, stills, bubble towers, and condensers for processing of fatting acids and so on.
Inconel 600 Specifications
Grade
UNS
W.Nr
Alloy 600
N06600
2.4816
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes
Inconel 600 Mechanical properties:(Minimum value at 20℃)
Tensile Strength
σb/MPa
Yield Strength
σp0.2/MPa
Elongation
σ5 /%
≥585
≥240
≥30
Inconel 600 Standards
Bar/Rod
Forging
Sheet/Strip
Wire
Pipe/Tube
ASTM B166
ASTM B366
ASTM B168
ASTM B166
ASTM B167
ASTM B163
ASTM B516
ASTM B517
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes

Inconel 600 Size Range

*Wire: Dia 0.08-12mm *Bar: Dia1.0-300mm *Strip(Coil): 0.2-20mm TCK x 10-300mm W *Sheet: min.0.7mm TCK x 1200mm W max. *Tube & Forging & Machine Parts: customized *Welding wire: 0.8mm,1.0mm,1.2mm,2.0mm,2.4mm,3.2mm,3.8mm,4.0mm etc *Welding Strip: 0.4-0.7mm TCK x 25-60mm W
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes
Our Advantages
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes
Recommend Products
Factory Price Inconel 600 601 617 Haynes 230 Seamless Pipe High Density ASTM B516 Inconel 600 Seamless Pipes

FAQ
Q: Does this tubing come with triclamp ends to be coupled together?
A: This particular tubing comes without tri-clamp ends standard. We can always weld tri-clamp ferrules to the end of tubes for any specific length you need. These products are referred to as tri-clamp spool assemblies. If you need a specific length, please
contact us.
Q: Are you able to cut tubing to lengths that don't require freight shipping? Say 5' lengths for example.?
A:Yes, we are able to cut down to other sizes. UPS Ground is able to ship up to 7' without the tubing being considered "oversized".We do charge a cutting fee for this service, however. Please contact us for a quote.
Q:How much does 1 stick of 4" tube weigh?
A: One 20' Stick of 4" Sanitary Tubing weighs approximately 75 pounds.
Q:You list gauge of this tubing at 16, but the wall thickness at 0.065". Isn't 16 gauge 0.0625"?
A: The wall thickness and gauges are all displayed in the table below. Please contact us if you have any other questions.
Q: Do you sell tubing in anything less than cases? I need to order just over 400 feet but don't want to pay for two cases as this is More than I need.
A: We do sell tubing on an individual basis however there is a $50 "broken box" fee applied to any order less than an entire case.Since we don't offer a way to order individual tube pieces online please call us to place an order over the phone.
Q: Do this product ship via freight?
A: Yes, our tubing comes in standard 20 foot lengths and will need to ship via freight. I'd also like to mention that there is a broken box charge meaning that if you do not order an entire box of tubing you will be charge additional fees as such. For more information please contact us. Thanks.
